Body Voltage Meter, incl. Accessories and Manual
For the measurement of body voltage, according to Erich W. Fischer, using a suitable multimeter.
The instrument is shipped with the suitable accessories: Hand electrode with 0.3m red measuring lead for connection to the multimeter plus 5m black measuring lead and a big gator clamp for the connection from multimeter to ground wire or other grounded parts like heating radiators or water pipes. For measurements of the body voltage, the instrument must be switched to ACV measuring range.
The instrument comes with a manuals which describes the procedure of body voltage measurement with this instrument and accessories.
Besides the body voltage measurements this digital multimeter can be used as a normal multimeter for the following measurements: AC and DC voltages and currents, resistance/capacitors/diodes/continuity and transistors.
Its dual slope A/D converter uses C-MOS technology for automatic zero adjustment, polarity selection and overflow.
Characteristics:
- 28 mm, 3 ½-dgt. LCD display with backlight, max. 2000
- manual range selection, low battery indication
- hFE-Test, Peak-Hold
-
with 200 mA automatic circuit breaker
- Auto power off
- Safety: EN 61010-1; CAT II 1000 V
- 200 mA automatic circuit breaker
- Accessories: holster, carrying case, hand electrode, test leads, gator clamp, typ-K- thermocouple probe, battery and manual
Technical data:Measuring ranges, accuracy:
| DCV: |
200 mV/2/20/200/1000 V; 100 µV; ± 0,5 % + 3 dgt. |
| ACV: |
200 mV/2/20/200/750 V; 100 µV; ± 0,8 % + 5 dgt.
200 mV/2/20/200/750 V; 100 µV; ± 0,8 % + 5 dgt.
Freq.-range: 40 ... 400 Hz |
| DCA: |
2/20/200 mA/20 A; 1 µA; ± 0,8 % + 3 dgt. |
| ACA: |
2/20/200 mA/20 A; 1 µA; ± 1,0 % + 5 dgt.
2/20/200 mA/20 A; 1 µA; ± 1,0 % + 5 dgt.
Freq.-range: 40 ... 200 Hz |
| Ohm: |
200 Ohm/2/20/200 kOhm/2/20/2000 MOhm; 0,1 Ohm; ± 0,8 % + 3 dgt. |
| Cap.: |
20/200 nF/2/20/200 µF; 10 pF; ± 2,5 % + 20 dgt. |
| Induct.: |
2/20/200 mH/2/20 H; 1 µH; ± 2,5 % + 20 dgt. |
| Freq.: |
2/20/200/2000 kHz/10 MHz; 1 Hz; ± 0,5 % + 4 dgt. |
| Temp.: |
-20 ... +1000°C; 1°C; ± 1,0 % + 4 dgt. |
| Operation Voltage |
: 9 V-battery |
| Dimensions: |
100 x 190 x 35 mm (WxHxD) |
| Weight: |
400 g |
