MBASS30V3 Kit4, Air Sampling System with LKS100 and PS30 Sampling Heads

PSE Priggen

MBASS30V3 Kit4, Air Sampling System with LKS100 and PS30 Sampling Heads

SKU: H01-144

Category: Measuring Instruments

GTIN: 4069565000753

MBASS30V3 main unit

air sampling head LKS100

particle sampling head PS30

Superfast charger

USB interface cable

Software MBASS30Control

Manual

5.193,16 €

incl. 19% VAT , plus

: 6 - 8 Workdays (DE - int. shipments may differ)

set

: 6 - 8 Workdays (DE - int. shipments may differ)

MBASS30V3 Kit4, Air Sampling System with LKS100 and PS30 Sampling Heads

Kit4 consists of an MBASS30V3 main unit, the air sampling head LKS100 and the particle sampling head PS30.

The kit offers a price advantage!

The picture shows components which differ from the afore mentioned scope of delivery.

Additional sampling heads can be purchased later.

With the MBASS30 system and the corresponding sampling heads, the impaction and filtration processes can be performed.

MBASS30V3 gives you the flexibility you expect from a modern and robust microbiological sampling system.

Applications:

MBASS30V3 - ideal for microbiological monitoring of the air:

for examinations of microbiological loads indoors in expert surveys and in building biology
in clean rooms in the pharmaceutical industry
with the manufacture of medicines in pharmacies
in hygienically-sensitive production areas and facilities in the food industry
in medical environments with very stringent requirements in hygiene tests of ventilation and air conditioning systems (VAC)

Characteristics:

Battery operation, more than 22,000 litres air sampling with full charge

Electronic volume flow adjustment 30 litres/min and 100 litres/min

Sample volumes from 10 to 10,000 litres

Start delay selectable from 1s to 24h

Illuminated 4.3 inch colour display with two tripod threads.

Brushless fan motor

Enclosed guidance of the sample air to avoid contamination within the housing

USB interface for PC connection

USB interface for memory stick for exporting sampled data

Technical data:

Air flow: 30 l/min and 100 l/min controlled and monitored

Sample air volumes: Preselectable from 10 to 10,000 litres

Start-up delay: 1 second to 24 hours

Data storage: Ring buffer with 100 sets of sampling data including sampling process, exportable to USB memory stick and into software MBASSControl
Default settings: 10 individual default settings (description text, volume flow, volume start delay, storage of the sampling process)

Operator guidance: English / German

Display: Illuminated 4.3 inch colour display (109mm) with touch panel

Volume flow measurement: Integrated volume flow sensor, temperature and pressure compensated
Air conveying device: High-performance fan with brushless motor, closed air duct
Temperature sensor: Internal and connection for external optional temperature/humidity sensor HC2A-S

Power supply: Lithium polymer battery pack (up to 22,000 litres of test air with LKS100 per battery charge)

Charger :100 to 240 Volt AC, charging current 2 A

Dimensions [mm]: 180 x 160 x 255mm³ without sampling head (B x H x D)

Weight: 2950g with a PS30 sampling head

Tripod socket: UNC 1/4 inch (photo) and UNC 3/8 inch (microphone)

CE conformity: Conforms to EU guidelines on electromagnetic compatibility

Recommended calibration interval: After 150 hours sampling time, but at least every 2 years

Warranty: 24 months, battery: 12 months

Scope of delivery:
The MBASS30V3 kit4 comes complete with:

MBASS30V3 main unit

Air sampling head LKS100

Particle collector head PS30

Super-fast charger

Manual

USB connection cable

Software MBASS30Control for configuration, remote control and data exchange

Optional accessories:
+ Air sampling head LKS30
+ Filter adaptor FA30
+ Allergen sampling head AS100
+ Transport case
+ Temperature/humidity sensor HC2A-S
+ Carbon tripod
+ Tripod intermediate table DUOSTA
+ Quick-change adaptors
