Phoenix Inverter Compact 12/2000 230V VE.Bus

Victron Energy

Phoenix Inverter Compact 12/2000 230V VE.Bus

SKU: V0002230

Category: Power Management

GTIN: 8719076037514
HAN: CIN122200000

Input voltage: 9.5 - 17VDC
Output voltage: 230V/50Hz
Continuous output power: 2000VA
Pure sine wave output
Particularly high starting power
Parallel connection and 3-phase operation possible
Compact dimensions, low weight
Automatic load switch
Communication interface

940,10 €

incl. 19% VAT , plus

: 6 - 8 Workdays (DE - int. shipments may differ)

pcs.

: 6 - 8 Workdays (DE - int. shipments may differ)

Phoenix Inverter Compact 12/2000 230V VE.Bus

SinusMax – top technology

The inverter series was developed for commercial use and is suitable for a wide range of applications. The development aimed uncompromisingly at an inverter with a clean sine wave output and high efficiency. By using the latest hybrid HF technology, it was possible to present a quality product with compact dimensions and low weight that can easily deliver any desired power.

Highest starting power

A key feature of SinusMax technology is the particularly high starting power. This is not possible with conventional HF technology. The inverters are able to cope with the high starting currents of e.g. cooling compressors, tool motors and the like.

Practically unlimited power through parallel connection and three-phase operation

Up to six inverter units can be connected in parallel to increase performance. For example, six 24/5000 units can deliver 24kW / 30kVA power. Three-phase operation is also possible.

Load transfer to other AC sources: The automatic load transfer switch

For smaller power outputs, we recommend the Filax automatic transfer switch. This means that computers and other sensitive electronic devices can continue to operate with virtually no interruption, as the switching times are very short (less than 20ms).

Communication interface

These larger inverter models are equipped with a VE.Bus connection. All you need to connect them to your PC is our MK3-USB VE.Bus-to-USB interface (optional accessory).

Together with our VictronConnect or VEConfigure software, which can be downloaded free of charge from the manufacturer's website, the parameters of the inverters can be customized.

This includes output voltage and frequency, overvoltage and undervoltage settings and programming the relay. This relay can be used, for example, to signal several alarm conditions or to start a generator. The inverters can also be connected to a GX device (e.g. Cerbo GX) for monitoring and control.
