C-30ZX, Ozone Monitor with Alarm, 0.02 - 0.14ppm

Item number: C-30ZX

  • measuring range:†0.02 - 0.14ppm
  • LED bar display
  • cost-effective fixed mount ozone monitor
  • alarm can be switched off
  • analogue output
  • Category: Near-Earth Ozone


    788,97 €

    including†19% VAT.

    Exp. shipping time: ca. 2-3 weeks

    : 7 workdays

    pc.


    Description

    C-30ZX, Ozone Monitor with Alarm for fixed Ozone Monitoring,† 0.02 - 0.14 ppm

    For water treatment plants, pulp bleaching mills, ozone generator monitors, photocopier and laser printer centers, fumigation projects, HVAC and indoor air quality systems, vehicular pollution monitors, research labs and pilot plants, and wherever ozone exposure is possible: the C-30ZX has a very fast and continuous response. It is rugged and versitile. There are no touchy controls.
    • Continuous monitoring of the ambient air quality. The ozone concentration of the air is displayed via the coloured LED bar scale.
    • An alarm tone sounds, when ozone concentration in the air exceeds 0.1ppm (another limit value can also be set).
    • Data output for data aquisiton and controlling a remote alarm or other equipment enausgang
    • Very easy to install. The handling of the ozone meter is simple and doesn't need any special knowledge.
    • Effectively no maintenance necessary.
    • The most cost-effective ozone monitor with alarm tone and analog output on the market!

    Technical data:
    Measuring Principle: HMOS (Heated Metal Oxide Sensor), diffusion
    Measuring range: 0.02 to 0.14ppm on the LED bar†display,
    †††††††††††††††††††††††† † † 0.02 to 0.30ppm via an external (optional) display.
    Response time: Within tenths of seconds of ozone reaching the sensor
    Sensitivity: Detection threshold at 0.02ppm
    Accuracy: 10-20%, depending on the conditions

    Coloured LED bar display: green (normal),
    ††††††††††††††††††††††††††††††††††††††††† yellow from 0.05ppm (caution),
    ††††††††††††††††††††††††††††††††††††††††† red from 0.1ppm (danger).
    Analog output: 0-3VDC for connection of a voltmeter or a datalogger
    Relay switching output: changeover, max.30V ACor DC / 1A
    †††††††††††††† Interface with analog and I/O signal for data loggers
    †††††††††††††† and for controlling a remote alarm or other equipment.
    Ozone concentration which triggers the alarm can be set (standard: 0.1ppm)
    Response time: a few 10 seconds
    Power supply: 12 VDC, 300 - 500mA, European power supply 230VAC is included
    Sizes: 85 x 35 x 60mm≥
    Weight: 140g
