VT500-30-, AC Voltage Transmitter

Item number: VT500-30-ff

VT 500-30-, AC Voltage Transmitter

Category: Measuring Transducers

Supply Voltage:

322,49 €

including 19% VAT.

Exp. shipping time: ca. 1-2 weeks

There are variations of this item. Please select the variation you wish.


Description

VT500-30-, AC Voltage Transmitter

To this transmitter AC voltages can be connected in 6 different measuring ranges.  The selection of the measuring range is done via a front side switch.
The device converts true r.m.s. voltage measuring values of all types of waveforms into industry standard signals for process control systems.

Features

  • 6 voltage measuring ranges, +/-35% adjustable
    0 ... 100 / 200 / 300 / 400 / 500 / 600V AC
  • Frequency range: 40 ... 2000Hz, basic wave (16 2/3 Hz on request)
  • Accuracy: 0.5%;
                   0.2% with optional calibration for one range
  • Switch selectable averaging function
  • Outputs 0/4 ... 20mA and 0/2 ... 10V DC
  • Rise time (t90) < =20ms
  • Current burden max. 1000 Ohm
  • 0-point and measuring span adjustable
  • Full 3-port isolation

Standard case for DIN rail mounting TS35
       Floor space: 22.5x75mm (WxH)
       Mounting height: 110mm

This transmitter is available in 2 versions for different supply voltages without surcharge.
Please specify when ordering:
VT 500-30-0: supply voltage: 230 V AC ± 10 %
VT 500-30-5: supply voltage:   24 V DC ± 15 %
