IM806V3 Lab Ionometer for Air Ion Measurement, Professional Instrument

Item number: H01-023

  • laminar air flow
  • open measurement system
  • illuminated graphical display
  • autonomous periodic zero-offset adjustment
  • battery and mains operation
  • USB device interface for PC connection
  • USB host interface for external memory stick
  • RS232 interface for easy integration into manufacturing systems
  • Network interface (10/100 Mbit)
  • integrated 1GB microSD memory card (Industrial grade)
  • robust aluminum housing
  • compact dimensions
  • fan monitoring
  • configurable analog outputs
  • integrated barometric pressure sensor
  • socket for optional external climate sensor HC2A-S

Category: Ion Concentration


5.732,23 €

including 19% VAT.

Exp. shipping time: ca. 1-2 weeks

: 7 workdays

pc.


Description

IM806V3  Lab Ionometer for Air Ion Measurement, Professional Instrument

Precise measurements of air ions in indoor areas, function rooms, production areas and vehicles is becoming ever more vital. Due to their low electrical charge, air ions demand high technical requirements of the ionometer, which is the measurement device used to measure the ion concentration. The ionometer IM806V3 - the successor of the IM806 and IM806V2 - features two measurement channels for simultaneous measurement of air ions with positive and negative electrical charges.


 The advantages of the IM806V3:

  • laminar air flow
  • open measurement system
  • illuminated graphical display
  • autonomous periodic zero-offset adjustment
  • battery and mains operation
  • USB device interface for PC connection
  • USB host interface for external memory stick
  • RS232 interface for easy integration into manufacturing systems
  • Network interface (10/100 Mbit)
  • integrated 1GB microSD memory card (Industrial grade)
  • robust aluminum housing
  • compact dimensions
  • fan monitoring
  • configurable analog outputs
  • integrated barometric pressure sensor
  • socket for optional external climate sensor HC2A-S
  • optional extension tube



Functionality (please see the English block diagram):
The measuring system consists of two outer electrode tubes (1 & 2), each of which holds a centric and electrically insulated smaller electrode. A DC potential is applied between the outer and inner electrodes, thus generating a DC electric field between the electrodes. The fan (4) continuously draws air at a defined flow rate through both of the electrode tubes. The DC electric field exerts a force in the vicinity of the electrodes on the ions in the streaming airflow (Coulomb’s law) and deflects them to the inner electrodes. Since the polarities of the applied voltage differ in both electrodes, one electrode accelerates the positively charged ions and the other electrode the negatively charged ions to the inner electrode. The air flow velocity, the level of the deflection voltage and the geometry of the electrodes are dimensioned such that ions of a defined ion mobility reach the inner electrode. Air ions of lower ion mobility (medium and large ions) only partially reach the inner electrode.

At very high ohmic resistances (R) (up to 1011 ohm), the charge current flowing during the charge neutralisation generates a measurable drop in voltage, which is boosted using suitable measuring amplifiers (3) to a measurable signal proportional to the air ion concentration and then digitalised in the pre-amplifier (6).

The entire sequence of operations is controlled by microcontroller (5) which also handles the display, the storage logic, the analog outputs (7), the USB interfaces, the RS232 interface, the network interface and the climate sensors.

The IM806V3 has an integrated barometric pressure sensor.

A temperature and humidity sensor (T/H sens) is also optionally available for recording the air temperature and relative humidity.
Climate data also gets recorded.



Ionometer IM806V3  applications:

  • Building biology and environmental analysis for verification of the indoor climate and the swift detection of ionizing radiation (e.g. from radon gas) and recording of electrical DC fields due to ion reduction
  • Quality assurance in industry for verification of ionizers in the production process
  • Air conditioning, ventilation and filter technology for the qualitative checking of air conditioning systems (RLT)
  • Medical technology for research, development and product monitoring
  • Ionized production areas for resource monitoring
  • Radiological research facilities and manufacturers
  • The vehicle industry for development and quality assurance of ventilation and air conditioning units


Technical data:

Measuring system:

Open measuring system without absorbent parts and with two electrodes arranged in parallel for simultaneous recording of negatively and positively charged air ions with an ion mobility of 1.3 cm²/Vs (small ions) and faster
Flow rate of sampling air: 24.5 l/min per channel, via integrated fan, approx. 1.8 m/s at inlet
Measuring ranges: Eight measuring ranges from 0 ... 1,000 Ions/cm³ up to 0 ... 40,000,000 Ions/cm³, automatic measuring range switchover
Zero-offset adjustment: Manually and automatically at definable time intervals
Warm-up time: Minimum: 30 seconds, typical: 15 minutes
Measurement display: Numeric display and graphical representation on illuminated colour display
Display and operation: Illuminated 4.3-inch-colour display (109 mm) with touch panel
Climate data: Integrated air pressure sensor, optional temperature / humidity sensor attachable
Storage of measurements: Ion measurements (min., average and max. value), air pressure, temperature*, humidity*, device state onto integrated microSD memory card in CSV format. Data transfer via integrated FTP server and PC software IMControl for Microsoft Windows 7 and higher (included in delivery). * with optional temperature / humidity sensor HC2A-S
Analog outputs: One output per channel 0 ... 10 VDC / 0 ... 20 mA, lower and upper limits definable. Both outputs are galvanically isolated from the measuring device. Voltage output: minimum input resistance of follow-on device: 10 kOhm Current output: maximum load resistance of follow-on device: 400 Ohm
Battery operation: Integrated lithium polymer battery (up to 15 hours operating time)
Charger: 100 to 240 Volt AC, charging current max. 2A
Device connections: Charging socket, 4 mm socket for discharging electrical static fields, USB port (Type A), USB port (Type mini-B), RS232 (9-pos. SubMinD socket), analog output (9-pos. SubMinD plug), connector for rotronic temperature / humidity sensor HC2A-S, network port (RJ45)
Ambient conditions: Temperature: 0 ... 45°C, humidity: 25 ... 90% RH., non-condensing
Network services: Web server, FTP server, remote control
Data storage: Internal 1GB microSD memory card, optional external USB memory stick
Dimensions / Weight: 246mm x 108mm x 226mm (W x H x D) / 3080g
Housing / Tripod sockets: Anodised aluminium profile housing / UNC 1/4 inch (photo) and UNC 3/8 inch (microphone)
Warranty: 24 months (limited to 12 months for battery and servo drive)


Scope of delivery:

  • IM806V3 measurement device
  • quick-charger
  • manual
  • USB cable
  • grounding cable with clip to drain off charges
  • IMControl software for configuration and measurement data processing
