Peak Tech 1660, Digital Power Clamp Meter, 4-digit, 750kW, with USB

Item number: P1660

  • 4-digit LCD-display (max 9999) with backlight and 42-segment bargraph
  • USB Interface / MIN/MAX and DATA-Hold
  • Auto power off and low battery indication
  • Current measurement up to 1000 A AC
  • conductor size: 55 mm
  • Con contact voltage detector
  • Analysis for single phase and balanced 3 phase systems
  • True RMS
  • True, apparent- and reactive power and power factor measurement
  • Data-memory for 99 values
  • Category: Current Clamp Meters


    173,74 €

    including 19% VAT.

    Exp. shipping time: ca. 1 week

    : 7 workdays

    pc.


    Description

    Peak Tech 1660, Digital Power Clamp Meter, 4-digit, 750kW, with USB

    Power clamp meter for measurements of power con-sumption, as well as the energy consumption in single-phase - or three-phase systems.

    In addition to other measurement functions, i.e. AC voltage - and current, phase angle or power factor is this power clamp meter capable of during a voltage measurement to determine the actual absorbed power.

    The rugged, rubberized and ergonomically shaped case that ensures a safe handling during the measurement and also suitable for use in industrial applications.

    • 4-digit LCD-display (max 9999) with backlight and 42-segment bargraph
    • USB Interface / MIN/MAX and DATA-Hold
    • Auto power off and low battery indication
    • Current measurement up to 1000 A AC
    • conductor size: 55 mm
    • Con contact voltage detector
    • Analysis for single phase and balanced 3 phase systems
    • True RMS
    • True, apparent- and reactive power and power factor measurement
    • Data-memory for 99 values
    • safety: EN-61010-1, CAT III 1000 V
    • Sccessories: carrying case, safety-test leads, USB interface cable, software for Windows XP/Vista/7, battery and operation manual



    Technical data:
    ACV: 15/100/300/750 V +/- 1.2 % + 5 dgt
    ACA: 40/100/400/1000 A +/- 2.0 % + 5 dgt
    true power: 0,60 - 750 kW +/- 3.0 % + 5 dgt
    apparent power: 0.60 - 750 kVA +/- 3.0 % + 5 dgt
    reactive power: 0.60 - 750 kVAr +/- 4.0 % + 20 dgt
    power factor: 0.3 - 1 +/- 2.0 % + 20 dgt
    phase angle: 0 - 90° +/- 1°
    frequency: 20 - 200 Hz +/- 0.5 % + 5 dgt
    energy: 1 - 9999 kWh +/- 3.0 % + 2 dgt
    operation voltage: 9V-battery
    dimensions (WxHxD): 100 x 295 x 45 mm³
    weight: 540 g
