S4AI, RS-485 MODBUS Module with 4 Analogue Inputs

Item number: S4AIff

  • Processing 4 analog signals (standard signals or different temperature sensors) to RS-485 MODBUS
  • Programmable individual characteristics of the inputs
  • Operation in Modbus Slave mode
  • Possible connection to the internal lateral RS-485 port
  • Two programmable alarm outputs
  • Mathematical functions: addition, subtraction, multiplication, division, average, minimum, maximum
  • Two virtual measurement channels to perform mathematical functions on the channels or between the measurement channels
  • Programmable operating time counters
  • DIN rail mounting
  • Galvanic isolation between inputs divided into 2 groups of 2 inputs
  • Possibile configuration via USB (power supply of the module is not required therefore)
  • 3 years warranty
  • Category: RS-485/MODBUS Components

    Inputs/Supply Voltage

    Price on application

    Exp. shipping time: ca. 1-2 weeks

    There are variations of this item. Please select the variation you wish.


    Description

    S4AI, RS-485 MODBUS Module with 4 Analogue Inputs

    The S4AI module from LUMEL is designed to measure standard signals (voltage, current) or readings from resistance or thermocouple temperature sensors, etc. and to provide the measured values in a digital form via the MODBUS protocol.
    Input signals are divided into two groups of two inputs which are insulated from each other.
    RS485 interface and USB are galvanically isolated from the input, output signals and from the power supply.
    The module configuration is possible via the USB PORT or one of the available RS-485 interface portswith the use of free eCon software.
    The RS-485 inteface can be connected via the connection terminals but also via the connections on both sides of the module under plastic covers which need to be removed for access. The lateral interface donnections offer the advantage that other modulse which also have side interfaces can easily be connected to each other using an optional inter-modular connector.


    The S4AI module has the following features:
    • analogue inputs (current / voltage or resistance / shunt / thermocouple, depending on the module variant)
    • programmable individual characteristics of the inputs
    • MODBUS protocol on RS485 interface
    • timers of lower and higher threshold overrun duration for each input of the module


    Technical data:
    4 analogue inputs: voltage/current standard signals orPt100, Pt500, Pt1000, type J, K, S thermocouples, shunt(please select when ordering!)
    Measuring ranges:
    Voltage standard signal: 10V
    Current standard signal: 20mA
    Pt100: -200to +850C
    Pt500: -200 to +850C
    Pt1000:-200 to +850C
    Thermocouple type J: -210 to +1200C
    Thermocouple type K: -250 to 1372C
    Thermocouple type S: -50 to 1768C
    Shunt: 150mV
    Output: Digital interface: RS-485, MODBUS RTU
    Alarm output: logic (off state: 0V; on state: 5V), max. output current: 20mA,
    Supply voltage: 85-253VAC/90-300VDC or 20-40VAC/20-60VDC (please select when ordering!)
    Dimensions:53 x 110 x 60,5mm
    Weight: 200g
    Housing protection: IP50 (front); IP00 (terminal)
    Mounting: DIN rail
    Warranty: 3 years
