Peak Tech 1625, Clamp Meter,40/400/1000A AC/DC

Item number: P1625

  • 3 ¾ digit, 15 mm LCD; max. indication: 3999, 42-segment analogue bargraph
  • True rms
  • Auto ranging
  • Min./Max. mode
  • data hold
  • backlight
  • AC/DC current: 1000 A
  • AC/DC voltage: 600 V
  • Resistance, frequency, capacitance and temperature measurement
  • Diode test and continuity test
  • Auto power off
  • max. conductor size: 31 mm
  • Category: Current Clamp Meters


    141,61 €

    including 19% VAT.

    Exp. shipping time: ca. 1 week

    : 7 workdays

    pc.


    Description

    Peak Tech 1625, Clamp Meter,40/400/1000A AC/DC

    This professional clamp meter allows contactiess current measurements and features a rugged fireproof and ergonomic double mold housing the tear drop shaped jaws can be used easily in industrial and commercial applications or in other tight places.

    • 3 ¾ digit, 15 mm LCD; max. indication: 3999, 42-segment analogue bargraph
    • True rms
    • Auto ranging
    • Min./Max. mode
    • data hold
    • backlight
    • AC/DC current: 1000 A
    • AC/DC voltage: 600 V
    • Resistance, frequency, capacitance and temperature measurement
    • Diode test and continuity test
    • Auto power off
    • max. conductor size: 31 mm
    • Safety: TÜV/GS, EN 61010-1; CAT III 600 V
    • Accessories: type K temperature probe, carrying case, test leads, 9V battery and manual


    Technical data:
    DCV 400 mV/4/40/400/600 V; ± 0,8 % + 2 digits;  100 µV
    ACV 400 mV/4/40/400/600 V; ± 1,5 % + 8 digits; 100 µV
    DCA 40/400/1000 A; ± 2,8 % + digits; 10 mA
    ACA 40/400/1000 A; ± 2,8 % + digits; 10 mA
    Ohm 400 Ohm/4/40/400 kOhm/4/40 MOhm; ± 1,0 % + 4 digits; 100 mOhm
    Kap. 4/40/400 nF/4/40/400 µF/4/40 mF; ± 3 % + 5 digits; 1 pF
    Freq. 4 kHz; ± 1,5 % + 2 digits; 1 Hz
    Temp. -40 ... +1000°C; ± 2,5 % + 3 digits; 1°C
    Dimensions (WxHxD) 80 x 230 x 50 mm³
    Weight 300 g
